ST
|
Specification |
ST | |
|
Generator |
Type |
Brushless,Revolving Magnetic Field, Self-excitating, 2 Poles, Single-phase |
|
Frame |
— | |
|
Rate AC Output |
650W/850W | |
|
Max.AC Output |
850W/1000W | |
|
Frequency |
50HZ/60HZ | |
|
Voltage |
110/120/220/240V | |
|
Voltage Regulator |
Condenser | |
|
Power Factor |
Cosф=1.0 | |
|
Engine |
Model |
1E |
|
Type |
Forced Air-cooled, 2-Stroke, Single-cylinder, Reed Valve | |
|
Bore×Stroke |
| |
|
Displacement |
63ml | |
|
Recommended Fuel |
Unleaded Gasoline | |
|
Fuel tank capacity |
| |
|
Fuel consumption |
≤ | |
|
Engine Oil Capacity |
Gasoline and Oil mixing ratio 40:1 | |
|
Start Mode |
Recoil and hand-operated | |
|
Standard |
Oil Alert |
without |
|
Fuel Gauge |
without | |
|
AC Voltmeter |
without | |
|
Voltage Transfer Switch |
without | |
|
Indicator Light |
with | |
|
AC Circuit Breaker |
with | |
|
Electric Starter |
without | |
|
Option |
DC socket (12v/ |
with |
|
DC Circuit Breaker |
with | |
|
Foam Packing |
with | |
|
|
without | |
|
Handle |
without | |
|
4 Wheel |
without | |
|
Set |
Cont. working time |
5.9-6.3h |
|
Noise level ( |
60-61dB(A) | |
|
Packing Dimension L×W×H |
405×345× | |
|
Net Weight |
| |
|
Gross Weight |
| |
|
Per 20' GP CNT |
550Sets | |
|
Per 40' GP CNT |
1100sets | |
